Screen Guard Cutting Machine

Phone Film Cutting Machine

Screen Guard Cutting Machine、 Screen guard cutting machines、 Screen Protector Cutting Machine

Product Parameters

CONTROL：APP control / Bluetooth
LCD TOUCH SCREEN : 5.5″ HD with system
CONNECTION : WIFI / Bluetooth
CUTTING SPEED:50-500mm/s
INPUT:100-240V
OUTPUT:24V/DC 2A
POWER:<100W
WORKING ENVIRONMENT:+5°C – +35°C

MAX MEDIA WIDTH : 310mm
MAX CUTTING WIDTH:230mm
CUTTING ACCURACY: 0.1mm
MACHINE SIZE: 570*220*180mm
NET WEIGHT:6kg
GROSS WEIGHT:8kg
PACKAGE SIZE:630*300*320mm
COLORS: White / Black

The Screen Guard Cutting Machine from Hoenter is an advanced, precision-driven tool designed to streamline the production of customizable screen protectors for smartphones, tablets, smartwatches, and more. Built for high-volume use, this machine offers a fast and efficient solution for businesses and retailers that provide on-demand screen protector services.

Key Features of Screen Guard Cutting Machine:

Precision Cutting: Utilizing cutting-edge technology, the machine delivers highly accurate cuts tailored to fit any device model, ensuring a perfect edge-to-edge fit.
Customizable Templates: Equipped with an extensive library of device models, users can select from a vast range of preset templates, or upload new ones to meet the specific demands of emerging devices.
Hydrogel Film Compatibility: Specially designed to cut hydrogel films, ensuring smooth application with maximum durability, protection, and transparency.
User-Friendly Interface: The machine boasts an intuitive touchscreen interface for quick setup and operation, allowing for easy selection of device models and cutting templates.
Fast Production Speed: Capable of delivering a fully cut screen guard within seconds, the machine boosts production efficiency while minimizing waste.
Durability and Longevity: Constructed with high-grade materials and components, the machine ensures reliability and a long service life, suitable for both large-scale production facilities and retail stores.
Compact Design: Space-efficient, the machine fits seamlessly into various work environments, making it ideal for stores with limited space.

Applications:

Retail shops offering on-demand screen protector services
Wholesale businesses specializing in mobile accessories
Customization centers for mobile devices

The Screen Guard Cutting Machine empowers businesses with flexibility, enabling them to cater to an ever-growing market of device models while maintaining a fast turnaround time and premium quality.

How to Start Your Business with Our Screen Guard Cutting Machine?

Preparation

Place our material

Prepare the Workspace: Ensure that your work area is clean, flat, and free from dust. Gather all necessary materials, including the screen protector cutter, screen protector sheet, and the device you intend to cover.

Select the Template: Depending on the model of your device, choose the appropriate template or cutting guide within the cutter. Most cutters have pre-installed templates for various devices or allow you to upload a custom template.

Cut

Choose a model to cut

Adjust Cutter Settings: Adjust the cutting depth and speed according to the thickness of the screen protector material. Ensure these settings are accurate to avoid tearing or undercutting.

Initiate the Cutting Process: Start the cutting process by pressing the designated button or following the machine’s operating instructions. Monitor the process to ensure the cutter operates smoothly without any interruptions.

Apply

Apply the screen protector

Apply the Protector to Your Device: Align the cut screen protector with your device’s screen, and apply it carefully, starting from one edge and gradually pressing it down to eliminate air bubbles.

Final Inspection: Once applied, inspect the screen protector to ensure proper alignment and adhesion,ensure there are no remaining bubbles or dust particles trapped beneath the protector.

Know More About Us

Modern And Dynamic Working Office

Designed with productivity in mind, our office space blends functionality with comfort, creating an environment where creativity thrives. Large windows flood the office with natural light, enhancing the well-being and motivation of our employees. We believe that a positive work environment leads to better results, which is why we’ve also incorporated ergonomic furniture and wellness areas, promoting a healthy work-life balance. Each workstation is equipped with the latest technology, ensuring that our team can operate at peak performance, whether they’re managing projects, coordinating logistics, or developing new strategies.

State-of-the-art Clean Room Facility

Equipped with cutting-edge filtration systems, our clean room operates at an ISO Class 5 standard, maintaining an environment with less than 100 particles per cubic meter. This ensures that your products are manufactured in an atmosphere where purity and precision are prioritized. Our facility is staffed by highly trained professionals who adhere to rigorous protocols, ensuring every aspect of production meets or exceeds your quality expectations.Our clean room is meticulously maintained to ensure a controlled environment, free from contaminants such as dust, airborne microbes, and chemical vapors. This stringent control is critical for producing high-quality products that require exacting cleanliness.

Quality Control Department

Our department is equipped with state-of-the-art inspection technology that meticulously examines each screen protector for clarity, thickness, and edge precision. From the raw material stage to the final product, our team of skilled quality control experts performs rigorous tests to detect and eliminate any imperfections, such as bubbles, scratches, or misalignments.We utilize advanced optical testing methods to guarantee that each screen protector provides crystal-clear visibility and seamless touch sensitivity. Additionally, our adherence to stringent industry standards ensures that our products are not only durable but also provide optimal protection for various devices.

Frequently Asked Question

Cutter and it's Material

What types of materials can the screen protector cutting machine handle?

The machine is designed to cut various materials commonly used for screen protectors, such as TPU (Thermoplastic Polyurethane), PET (Polyethylene Terephthalate), and other screen protector films.

How accurate is the cutting precision of the machine?

The screen protector cutting machine offers a cutting precision of 0.1 mm, ensuring a perfect fit for the screen protectors on different devices.

Can the machine cut protectors for all types of devices?

Yes, the machine is versatile and can cut protectors for a wide range of devices, including mobile phones, tablets, laptops, smartwatches, and camera lenses. Different sizes can be cut into different models. According to different sizes, we divide them into Mini / Phone / Tablet / Laptop screen protector cutting machine.

Is the machine easy to operate for beginners?

Absolutely! The machine is user-friendly, with an intuitive interface that allows even beginners to operate it efficiently with minimal training.

How fast can the machine cut a screen protector?

The cutting speed varies depending on the material and design, but typically, it can cut a standard phone screen protector in less than 30 seconds.

Does the machine support customization for different screen sizes?

Yes, the machine allows for customizable settings to cut screen protectors of various sizes, ensuring a perfect fit for each device model.

How durable are the screen protectors cut by the machine?

The screen protectors, particularly those made from TPU, are highly durable, offering excellent protection against scratches, impacts, and other potential damage.

What maintenance does the screen protector cutting machine require?

Regular maintenance includes cleaning the cutting blades, checking for software updates, and ensuring the machine is free of dust and debris to maintain optimal performance.

Can the machine connect wirelessly to a computer or mobile device?

the machine features Wi-Fi and Bluetooth connectivity, allowing for easy, wireless operation from your smartphone.
